Using 3/8" Zinc Coated Wire Rope Cable for Antennas Wire

Writer: skylarkcolo
skylarkcolo
Jan 19, 2021
15 min read

Updated: Aug 22

A photo of the 100 foot wood poles in use at Steve Walz K0UO RSI Corp AI data test center and antenna farm, showing the zinc 3/8 wire rope cable used for the arrays
K0UO uses 3/8" Zinc Triple Coated Wire Rope Cable for Antennas Wire

At HF (3–30 MHz), the phenomenon known as skin effect becomes a critical factor in the behavior of radio frequency (RF) currents and large antenna wires. Skin effect refers to the tendency of alternating current to flow primarily on the surface of a conductor rather than through its entire cross-sectional area. This effect is particularly pronounced at higher frequencies, such as those found in the HF band. As a result, the effective resistance of a conductor is not solely determined by its material properties but is significantly influenced by its surface area, which is directly tied to the perimeter of the wire. The greater the surface area available for current flow, the lower the effective resistance, making it essential to consider both the geometry and the material when evaluating conductors for RF applications.

an actual photo of Steve Walz climbing a tower at the K0UO site, which is the largest ham station and antenna farm in the world of 1200 acres near Kiowa, KS
Steve Walz "K0UO" climbing a large antenna tower

"K0UO, Miles of WIRE, in the AIR, and ON the AIR daily"

When examining 3/8 in zinc coated wire ropes used in RF applications, it is important to note that their diameter is approximately 4.6 times larger than that of standard 12 Ga copper wire conductors. This substantial increase in diameter translates to a corresponding increase in perimeter and surface area, which is critical for effective current flow. Specifically, the larger diameter of the wire rope provides it with roughly 4.6 times more surface area compared to a conventional wire of smaller diameter. This increased surface area is advantageous, as it allows for a more efficient flow of RF current, thereby reducing the overall RF resistance encountered during transmission.


Furthermore, it is essential to understand how RF resistance behaves in relation to the diameter of the conductor. At HF frequencies, the relationship between resistance and diameter can be described as roughly inverse; that is, as the diameter increases, the RF resistance tends to decrease. This characteristic is due to the fact that more surface area facilitates a greater flow of current, resulting in lower resistance encountered by the RF signals.


Consequently, the size advantage offered by wire rope—despite steel's inherent lower conductivity compared to materials like copper—often compensates for the conductivity disparity. This is primarily due to the significant benefits that larger conductors provide in terms of mechanical strength, durability, and resistance to environmental factors. In many practical applications, particularly in industries such as construction, mining, and marine operations, the robustness of wire rope becomes a critical factor.


The larger diameter of wire rope allows it to carry greater loads, which is essential in applications where heavy lifting or tensioning is required. For instance, in construction cranes, wire ropes are used to hoist heavy materials to great heights. The strength of the wire rope, combined with its ability to withstand tensile forces, ensures that it can perform reliably under demanding conditions. This mechanical advantage often outweighs the disadvantages posed by lower electrical conductivity.


Wire ropes are typically constructed with multiple strands of zinc coated steel wires, which not only enhances their strength but also contributes to their flexibility and resistance to fatigue. This multi-strand design allows wire ropes to bend and flex without breaking, making them ideal for applications where movement is necessary, such as in pulleys and winches. The ability to withstand repeated bending cycles without significant wear or failure is a crucial factor in many industrial settings.


In addition, wire ropes are often treated with protective coatings, such as triple zinc galvanization, to enhance their resistance to corrosion and environmental degradation, also helps in reduced resistance loss. This treatment significantly extends the lifespan of the wire rope, making it a more cost-effective choice in the long run, particularly in harsh environments where exposure to moisture, chemicals, or extreme temperatures can lead to rapid deterioration of less robust conductors.


The installation and maintenance of wire ropes can be more straightforward than that of other types of conductors, such as those made from copper. Wire ropes can be spooled and managed with relative ease, and their strength means that they can often be used in longer spans without the need for additional support structures. This can lead to reduced installation costs and time, which is a significant consideration in project management.


In summary, the benefits of using a larger conductor, such as a zinc triple coated wire rope, often outweigh the drawbacks associated with using a material with lower conductivity. The combination of mechanical strength, durability, resistance to environmental factors, and ease of use makes wire rope a preferred choice in many applications, despite its lower conductivity compared to alternatives like copper. This balance of attributes ensures that wire rope remains a vital component in various industries, providing reliable performance in challenging conditions.

Thus, in most cases, the enhanced surface area provided by the larger diameter of zinc coated wire rope effectively mitigates the negative impact of its material properties, leading to improved performance in RF transmission scenarios.

photo of wire rope used at K0UO for the massive rhombic HF arrays diameter here largely compensates for loss
K0UO uses 3/8 in zinc triple coated wire rope for all his antennas

The Steel Advantage: Traveling-wave antennas rely on suppressing the reverse wave. Because galvanized steel acts as a distributed attenuator, it naturally absorbs residual reflected energy before it can travel back up the Rhombic or V beams legs.


Ferromagnetic effects in steel are significant phenomena that can lead to increased energy losses in conductive materials, particularly when dealing with wires of the same size. These effects arise from the alignment of magnetic domains within the steel, which can cause eddy currents to form when the material is subjected to alternating magnetic fields. As a result, these eddy currents generate heat, leading to energy losses that can be detrimental to the efficiency of electrical systems but not an issue for Rhombic arrays, which in most cases are terminated with non-inductive resistors anyway .


However, in the context of the wire being discussed, the massive diameter of the zinc coated steel wire plays a crucial role in compensating for these losses. The larger diameter not only allows for a greater volume of conductive material but also reduces the relative impact of the ferromagnetic effects on the overall performance of the wire. This is because the larger cross-sectional area provides a more effective pathway for electrical current, mitigating the influence of the eddy currents that contribute to energy losses.


Additionally, the practice of stranding, which involves twisting together multiple smaller wires to form a single larger conductor, introduces slight extra surface area that can further enhance the wire's performance. Stranding can improve flexibility and reduce the skin effect, where alternating current tends to flow near the surface of the conductor. The increased surface area from stranding allows for better heat dissipation and can help in maintaining a lower temperature during operation, which is critical in minimizing resistive losses.


In summary, while ferromagnetic effects in steel can indeed lead to increased losses in wires of the same size, however the substantial diameter of the wire in question significantly mitigates these losses. Moreover, the additional benefits provided by stranding, such as increased surface area and improved thermal management, contribute to a more efficient electrical conductor overall. This interplay between diameter, stranding, and ferromagnetic properties highlights the complexities involved in designing effective electrical conductors, particularly in applications where efficiency and performance are paramount.



The USSR Arrays Used Steel Wire Also

The decision by Grigory Zakharovich Ayzenberg and other Soviet engineers to use steel wire (often bimetallic steel-cored wire, or simply galvanized steel rope) instead of solid copper for massive traveling-wave rhombic arrays was a masterstroke of engineering. It perfectly balanced physics, economics, and harsh environmental realities.

While a traditional resonant antenna (like a dipole) requires highly conductive copper to maintain high efficiency and prevent power loss, a terminated traveling-wave antenna operates under fundamentally different principles.

The primary reasons steel was used include:

1. Mechanical Strength and Lower "Wire Sag"

Rhombic arrays are massive, often requiring leg lengths stretching hundreds of meters suspended on towers 30 to 50 meters high.

  • The Problem with Copper: Solid copper is relatively soft, heavy, and highly prone to stretching over time under its own weight. In the extreme Soviet climates—enduring heavy ice loading, high winds, and massive temperature swings—copper wires would stretch, sag heavily, and eventually snap.

  • The Steel Advantage: Steel wire or steel wire rope has immense tensile strength. It could be pulled tightly across vast spans, drastically reducing wire sag and ensuring the geometric symmetry of the rhombus remained perfectly intact despite severe weather.

2. The Unique Physics of Traveling-Wave Antennas

In a standard resonant antenna, RF current reflects back and forth, meaning resistive losses from a poor conductor like steel would severely degrade the antenna's performance. However, a rhombic is a non-resonant, traveling-wave antenna.

  • The Terminated Design: The RF energy travels down the legs in a one-way wave. Whatever power is left at the far end is completely absorbed by a termination resistor (or a lossy transmission line) to make it unidirectional.

  • Because it is a traveling-wave system, the input impedance and radiation pattern are heavily governed by the physical size and geometry of the array rather than the strict conductivity of the wire.

3. Exploiting the RF Skin Effect

To offset the lower DC conductivity of pure steel, Soviet engineers heavily utilized bimetallic wire (steel-cored wire clad in a thin layer of copper, similar to modern Copperweld).

  • Due to the skin effect, high-frequency alternating current does not flow through the center of a wire; it travels exclusively along the outer "skin."

  • By using a steel core clad in a thin layer of copper, Ayzenberg achieved the structural invincibility of a heavy steel cable while keeping excellent RF conductivity on the outer skin. Even when plain galvanized steel was used without copper cladding, the sheer physical thickness (surface area) of the wire rope kept the RF skin resistance manageable enough for the antenna to still achieve massive forward gain.

4. Suppression of Side Lobes (Sidelobe Damping)

A known quirk of extremely long-wire antennas is that they naturally generate a "morass" of unwanted secondary sidelobes. In some military and heavy commercial installations, the slight, inherent resistance of plain steel wire actually worked as a feature rather than a bug. It introduced a minor, distributed attenuation along the traveling wave, which naturally dampened and suppressed minor unwanted sidelobes, resulting in a cleaner, more tightly focused main directional beam.


real photo of K0UO unloading a 5000 foot roll of 3/8 wire rope cable used for the Rhombic array at the K0UO Steve Walz test range, AI data center testing site and antenna farm in Kiowa KS Barber country.  The spans between support poles are hundreds so 3/8 inch triple galvanized wire rope cable is use and is tensioned at over 1000 pounds, to remove the slack in the antenna cable.
The K0UO Antenna farm and testing range uses galvanized wire rope by the 5000 foot rolls. The spans between support poles are hundreds of feet a part, so 3/8 inch triple galvanized wire rope cable is use, and is tensioned at over 1000 pounds, to remove the slack in the antenna cable.

Cable with Zinc triple coating plays a significant role in the performance of antennas, particularly in the context of high-frequency (HF) bands. When operating on these higher HF bands, the phenomenon of skin effect becomes particularly relevant. Skin effect refers to the tendency of alternating current (AC) to flow primarily near the surface of a conductor rather than throughout its entire cross-section. In the case of zinc-coated cables, this means that at higher frequencies, the current predominantly travels along the zinc layer. This is due to the smaller skin depth associated with higher frequencies, which results in less penetration into the underlying steel core. However, when we shift our focus to lower frequency bands, the situation changes somewhat. While some of the current does penetrate into the steel core, it is important to note that the overall size and surface area of the cable still play a critical role in maintaining efficient conductivity.

When we consider the bottom line on efficiency, it becomes clear that the use of a 3/8" galvanized wire rope tends to offer slightly higher efficiency compared to a standard 12 gauge copper wire. This is largely attributable to the substantial surface area of the galvanized wire rope, which effectively compensates for any inherent material disadvantages that may exist when compared to copper. In practical terms, both types of wire can achieve impressive efficiency levels, typically exceeding 95% to 99% in common configurations such as HF dipoles, inverted-V antennas, and loop antennas. The losses incurred in these setups are often negligible when compared to other factors such as ground losses and matching network inefficiencies. The difference in performance between these two materials is relatively small, likely amounting to less than 0.5 dB, with a slight advantage favoring the thicker galvanized rope, particularly when operating on lower bands like 80 meters and 40 meters.

In addition to efficiency, there are other practical differences that should be considered when choosing between galvanized wire rope and copper wire for antenna applications.


Strength and Durability: One of the most significant advantages of wire rope, particularly galvanized wire rope, is its superior strength and durability. Unlike copper, which is a softer metal and can be prone to stretching or breaking under adverse conditions such as high winds, ice accumulation, or long spans, galvanized wire rope is designed to withstand these challenges. It maintains its integrity and shape even under substantial tension. For example, amateur radio operator K0UO has successfully utilized spans of 1200 feet with over a 1000 pounds of tension applied to the wire. This careful tensioning is essential to minimize sagging and ensure optimal performance of the antenna system. The ability of galvanized wire rope to endure these conditions without significant deformation makes it a preferable choice for many amateur radio operators and professionals alike, especially in environments where reliability and long-term performance are critical.

A view from a 200 foot high tower of the 3/8 in array cable nearly 200 feet in the air at the K0UO site, which is the largest ham station and antenna farm in the world of 1200 acres near Kiowa, KS
A view of the 3/8 in cable used on the K0UO arrays, the photo view from nearly 200 feet in the air

Weight and Handling — When comparing zinc coated wire rope and copper wire, one of the most significant differences lies in their weight and handling characteristics. Wire rope is typically much heavier and stiffer than copper wire, which can have implications for various applications. The increased weight of wire rope can lead to challenges in transportation and installation, as the equipment required to handle it must be robust enough to manage the heavier loads. Additionally, the stiffness of wire rope can make it more difficult to maneuver and position in tight spaces, especially in overhead applications or where flexibility is required. In contrast, copper wire tends to be lighter and more pliable, allowing for easier handling and installation. However, copper wire also has a tendency to sag under its own weight unless it is highly tensioned. When copper wire is under tension, it can stretch, which may lead to changes in frequency during operation. This stretching can affect the performance of the system in which the wire is used, particularly in applications involving RF signals or mechanical loads. Therefore, it's essential to consider these factors when selecting between zine coated wire rope and copper wire for specific tasks, as the choice can significantly impact the efficiency and effectiveness of the operation.

Corrosion — In terms of corrosion resistance, both zinc coated wire rope and copper wire can perform well under certain conditions, but there are important distinctions to consider. Bare or stranded copper wire is known for its excellent conductivity and resistance to corrosion, particularly in indoor settings where exposure to moisture and harsh environmental conditions is minimal. However, when exposed to outdoor elements, copper can develop a patina over time, which may impact its conductivity if not properly maintained. On the other hand, zinc galvanized wire excels in outdoor applications due to its superior long-term corrosion resistance. The galvanization process involves coating the wire with a layer of zinc, which acts as a protective barrier against moisture, salt, and other corrosive agents found in the environment. This makes zinc galvanized wire an ideal choice for outdoor installations, such as in marine environments or areas with high humidity, where the risk of rust and degradation is significantly higher. Therefore, when choosing between copper and galvanized wire, it is crucial to consider the specific environmental conditions and the expected lifespan of the installation to ensure optimal performance and durability.

phot on a array at 100 foot on one of the 40 wood power-line pole in use at 3/8 in wire rope in use at the Steve Walz antenna site, and AI center test range site near Kiowa KS on the 4KS airport,
A view of the 3/8 in wire rope in use at the Steve Walz, K0UO antenna site near Kiowa. KS, and at the 4KS airport and RSI Corp outdoor antenna test range site

Bandwidth — The concept of bandwidth in this context refers to the range of frequencies over which a system can operate effectively. When discussing wire rope, particularly in relation to radio frequency (RF) applications, it is important to consider the RF skin effect. This phenomenon occurs when alternating current (AC) flows through a conductor, causing the current to be distributed unevenly across the cross-section of the conductor. As frequency increases, the current tends to flow more on the surface of the conductor rather than throughout its entire cross-sectional area. Consequently, thicker wire ropes can accommodate a wider SWR (Standing Wave Ratio) bandwidth due to their increased surface area, allowing for improved performance at higher frequencies. This wider bandwidth is critical in applications where signal integrity and transmission efficiency are paramount.

When it comes to the choice of materials for wire rope, the decision often hinges on the specific requirements of the application. If maximum efficiency is the primary objective and factors such as tensile strength and durability are not of utmost importance, then copper wire is typically the preferred choice. Copper is renowned for its excellent electrical conductivity, which allows for minimal resistive losses and optimal energy transfer. For those seeking a compromise between conductivity and strength, copper-clad steel offers a hybrid solution that combines the superior conductivity of copper with the structural integrity of steel, making it suitable for various applications without sacrificing performance.

However, in scenarios where ruggedness, long-term reliability, or the ability to withstand high-stress conditions is essential, opting for a thicker wire rope becomes advantageous. The larger diameter of the wire rope not only enhances its mechanical strength but also contributes to its overall efficiency. This increased size allows for better handling of power and signal transmission, making it a preferred choice in demanding environments such as industrial settings, construction sites, or any application where durability is critical. The thicker wire rope can endure harsher conditions and maintain performance over extended periods, thereby reducing the frequency of replacements and maintenance. In summary, the choice between copper and thicker wire rope should be guided by the specific needs of the application, weighing factors such as efficiency, strength, and environmental conditions to achieve the best possible outcome for the intended use.

Model in software like EZNEC/4NEC2 with conductivity ~1–2e7 S/m for galvanized steel to confirm for your exact design/band.

Larger wire or cable size configurations can lower high-impedance loads, stabilize SWR, clean up side lobes, and widen operating bandwidths


A view of a 3 wire rhombic array using zine coated wire rope on a 100 foot wood pole
Using strong wire for a large array

Comparison of 3/8 in Zinc Coated Wire Rope and 12 Ga Soft Copper Wire for RF Antenna Construction

When it comes to RF antenna construction, the choice of materials plays a pivotal role in determining the performance, durability, and overall effectiveness of the antenna system. Two commonly discussed materials in this context are 3/8 inch zinc-coated wire rope and 12 gauge soft copper wire. Each of these materials brings unique properties and characteristics that can significantly affect the antenna's functionality.


3/8 Inch Zinc Coated Wire Rope

The 3/8 inch zinc-coated wire rope is primarily designed for heavy-duty applications, often used in lifting, rigging, and other industrial purposes. The zinc coating provides a layer of corrosion resistance, making it suitable for outdoor environments where exposure to moisture and other elements is a concern. This type of wire rope is typically composed of multiple strands of steel wire twisted together, which contributes to its strength and durability. When considering its application in RF antenna construction, the zinc-coated wire rope offers several advantages and disadvantages. **Advantages:** 1. **Strength and Load Bearing Capacity:** The construction of the wire rope allows it to withstand significant tensile forces, making it an excellent choice for installations that require stability and robustness. This can be particularly beneficial in locations prone to high winds or other environmental stresses. 2. **Corrosion Resistance:** The zinc coating protects the steel from rust and degradation, ensuring a longer lifespan, especially in outdoor settings where the antenna may be exposed to rain, humidity, and other corrosive elements. 3. **Flexibility in Installation:** The wire rope can be easily manipulated and secured in various configurations, allowing for creative antenna designs that might require specific angles or tensioning. **Disadvantages:** 1. **Electrical Conductivity:** While the zinc coating does provide some conductivity, it is not as efficient as copper. This reduced conductivity can impact the antenna's performance, especially in applications requiring high-frequency signals but the larger size RF skin effect will offset this. 2. **Weight:** The heavier nature of the wire rope can complicate installation and may require additional support structures, which could lead to increased costs and complexity in the setup.


12 Ga Soft Copper Wire

On the other hand, 12 gauge soft copper wire is widely recognized for its excellent electrical conductivity, making it a preferred choice for smaller RF antenna construction. Copper is known for its superior ability to transmit electrical signals, which is essential in the context of radio frequencies. **Advantages:** 1. **High Electrical Conductivity:** Copper wire offers one of the highest conductivity ratings among metals, which translates to minimal signal loss and improved performance for RF applications. This characteristic is crucial for antennas that need to transmit or receive signals over long distances or at high frequencies. 2. **Ease of Workability:** Soft copper wire is malleable and easy to bend, twist, and shape, allowing for intricate designs that can enhance the antenna's efficiency. This flexibility is particularly advantageous for creating custom antenna configurations tailored to specific frequency ranges. 3. **Lightweight:** The lighter weight of copper wire simplifies installation and reduces the need for extensive support structures, making it a more practical option for many DIY enthusiasts and professionals alike. **Disadvantages:** 1. **Corrosion Susceptibility:** Unlike zinc-coated wire rope, copper is prone to oxidation when exposed to the elements. This can lead to tarnishing and a gradual degradation of performance over time, particularly in humid or salty environments. Protective coatings or treatments may be necessary to mitigate this issue. 2. **Lower Tensile Strength:** While copper wire is strong enough for many applications, it does not possess the same load-bearing capacity as steel wire rope. This could limit its use in scenarios where high tension or heavy loads are involved.

Conclusion

In summary, the choice between 3/8 inch zinc-coated wire rope and 12 gauge soft copper wire for RF antenna construction hinges on the specific requirements of the application. For projects where strength and durability are paramount, especially in harsh outdoor conditions, the zinc-coated wire rope will be more suitable. Conversely, for applications where electrical conductivity and signal clarity are the top priorities, the soft copper wire is a good option. Ultimately, understanding the unique properties of each material will enable builders and engineers to make informed decisions that enhance the effectiveness of their RF antenna systems.

photo of the K0UO Logo uses a Rhombic diamond shaped Antenna,  also used in the ARRL and RSGB logos
The K0UO Logo, the ARRL and RSGB Diamond Logo, also looks like a Rhombic Antenna, which is the "PHD" of HF wire antennas
